H.264, H.265
Decoding Capability
1‑ch 3840 x 2160@25 Hz, 4‑ch 1080@30 Hz, 8‑ch 720P@30 Hz
Screen Control
Description
Split Screen
1/4/9 (supports simultaneous display of up to 8 channels)
Output
Description
Video Output Resolution
1920 x 1080@60 Hz
Output Interface
Description
HDMI Output
1 x HDMI output interface
Audio Output
1 x standard 3.5mm audio jack (reserved)
Other Interfaces
Description
Serial Port
1 x RS232 (DB9, reserved)
1 x RS485 (half‑duplex, reserved)
Network Interface
1 x 10M/100M adaptive Ethernet interface (RJ45)
USB
1 x USB interface (used to upgrade device and connect mouse)
Power
DC 12 V power interface
General
Description
Screen Size
10.2 inches
Joystick
four‑dimensional joystick
Max Power Consumption (W)
＜15
Product Dimensions (W x H x D) (mm)
449.7 x 178.6 x 115.4
Weight (Kg)
1.4
Operating Temperature
‑10 ～ 40°C
Operating Humidity
10% ～ 90% (No‑condensing)
Storage Temperature
‑40 ～ 60°C
