AC Input
Voltage
90～264V AC
Frequency
47～63Hz
Power Factor
≥0.95
Input Current
≤4A@100VAC
Input Protection
Input undervoltage, Input overvoltage
DC Output
Voltage/Current
+12VDC/25A, +12VStandby/0.7A
Output Power
312W
Output Efficiency
≥83%, 220V AC/25A
Line Regulation
±5%
Load Regulation
±3%
Regulated Voltage Accuracy
±5%
Dynamic Response Overshoot
±5%
Current Sharing Rate
±5%
Output Protection
Short Circuit Protection, Overload Protection, Overvoltage Protection, Hot Plug Protection, Over Temperature Protection
Other
Indicator light
Normal: green on, Abnormal: Yellow on
Working Temperature
0~55℃
Storage Temperature
-40~70℃
Working Humidity
10%~90%
Heat dissipation
Ventilating fan design, heat emission at back
Dimension (D × H × W)
234.9mm×40.13mm×101.6mm
Certification
EMC standards
EN55022, EN55024
NEBS standards
GR-63-CORE ISSUE 2
Approved standards
CB, FCC, UL
